Electronic Universal Tensile Testing Machine For Steel Wire Tensile Strength Test
Application:
The equipment is applicable to the manufacture of metal, adhesives, pipes, profiles, aerospace, petrochemical, waterproofing membranes, wire and cable, textile, fiber, rubber, ceramics, food, pharmaceutical packaging, geotextile, film, wood, paper, etc. The product quality supervision departments at all levels are also applicable to teaching demonstrations in colleges and universities.Tensile testing machine 50KN price computer controlled universal tensile testing machine.
Meet Standards:
ASTM D903, ASTM E8, JIS K6854, PSTC7, ASTM D903,GB/T16491, CNS-11888, JIS K6854, PSTC-7, ASTM E4, ASTM D828, ASTM D882, ASTM D1938, ASTM D 412, ASTM D3330, ASTM F88, ASTM F904,,JIS P8113, QB/T 2358, QB/T 1130, ISO 527, ISO 178, ISO 6259, ISO 7500-1, ISO 8339, ISO 37, etc.
Control Mode:
1. Constant speed
2. Fixed displacement
3. Constant load speed
4. Fixed load
5. Constant Strain inc. Rate
6. Constant Stress inc. Rate
7. Constant Stress inc. Rate- Constant Strain inc. Rate
Main technical parameters
| Model | XWW-1KN |
| Type | Single column model |
| Accuracy Grade | Class 1 (Class 0.5 optional) |
| Force-measuring Range | 1%~100%FS(0.4%~100%FS optional) |
| Deformation-measuring Range | 2%~100%FS |
| Deformation-measuring Accuracy | ±1% |
| Crossbeam Displacement Resolution | 0.001mm |
| Crossbeam Speed Range | 0.05~500mm/min |
| Displacement Speed Accuracy | ≤ ±0.5% |
| Metal Extensometer Accuracy Grade | ±0.5% |
| Tensile Space | 700mm |
| Compression Space | 1000mm |
| Clamps | Tensile, compression, bending fixture |
| PC System | Equiped with brand computer |
| Power Supply | AC 220V±10%, 50Hz (can be customized as customer request) |
| Size of the host | 400*400*1700mm |
| Packing size & Weight | 500*500*1800mm,about 120kg |
